SKU:A01-READER
Akuvox A01 RFID Card Reader Access Control Terminal
Login to buyThus saving your solution costs. Equipped with a card reader (125kHz and 13.5MHz) which is capable of handling a majority of cards in wide use currently, A01 is designed to provide you with greater flexibility and security than those traditional access control systems.
Features
- Toughened glass front panel & Aluminum alloy frame
- 13.56MHz & 125kHz RFID card reader & NFC
- 20,000 card capacity &100,000 event logs
- Multi-frequency RFID card reader;
- Support Tamper Alarm
- Card less access control via NFC
- Compatible with Akuvox cloud
- Water-proof & Dust-proof:IP65
- Installation:Wall mount & Flush mount
- 802.3af Power-over-Ethernet and 12V DC connector (if not using PoE)
- Compatible with 80 mm square mounting box (not included in delivery)
-
Vendor:
Akuvox
-
Type:
Access Control
- Description
The Akuvox A01 IP Access Control Terminal with RFID and NFC combines a dedicated door controller and credential reader within a single streamlined unit, offering an optimized solution for modern installations seeking reduced wiring footprint. Built for reliable daily security management, the A01 supports dual-frequency RFID card scanning alongside NFC mobile authentication, presenting versatile entry options at the door. Featuring standard IP network integration and browser-based administration, it provides a practical entry system suitable for standalone doorways or large-scale access control networks.
Product Overview
The Akuvox A01 serves as a compact access control terminal designed to unify core reading and control hardware at entry points. Built to simplify site infrastructure, it seamlessly processes credentials, door strike signals, and auxiliary inputs across varied architectural layouts.
Featuring integrated IP connectivity and flexible authentication methods, this unit gives system integrators the ability to secure doors cleanly and manage user permissions efficiently. Supplied by Total Security Equipment, it offers a robust base for scalable access control deployment.
Why Choose the A01
Select the Akuvox A01 when your facility requires a professional-grade access unit that eliminates hardware clutter without sacrificing functionality. Integrating both controller and card reader into one frame simplifies mounting procedures, reduces wiring overhead, and minimizes total hardware expenditure compared to multi-box setups. Supporting dual RFID frequencies alongside NFC mobile credentials, it allows staff, visitors, and contractors to gain access using their preferred method. Combined with 802.3af PoE support, IP65 weather resistance, and web-based configuration, the A01 delivers dependable daily operation across commercial buildings and multi-tenant environments.
Key Capabilities
All-in-One Controller + Reader
Combines access processing and credential reading into a single hardware footprint, simplifying installation and maintaining clean door aesthetics.
Multi-Credential Access (RFID + NFC)
Supports multi-frequency RFID proximity cards and NFC mobile access, tailoring entry options to match site workflows and user preferences.
Networked IP Operation
Communicates over Ethernet via TCP/IP, ensuring seamless integration into centralized access management networks across multi-door sites.
Browser-Based Configuration
Configured directly through a web browser, eliminating proprietary setup tools and standardizing system commissioning for technicians.
Outdoor-Ready Durability
Protected by a robust, IP-rated enclosure designed to withstand outdoor environmental exposure like rain, dust, and temperature shifts.
Key Features
- • RFID + NFC credential support: Dual-frequency RFID compatibility accepts standard physical cards, while NFC enables smartphone authentication for modern credential workflows.
- • 802.3af PoE or 12V DC power: Power the device directly over Ethernet via PoE for cleaner cabling, or utilize 12V DC auxiliary input where network power is unavailable.
- • Relay output + input support: Equipped with 1 relay output and 2 digital inputs to trigger electronic locks, request-to-exit buttons, and door status sensors.
- • Tamper support for added protection: Built-in tamper switches raise immediate alerts upon physical device manipulation, enhancing perimeter monitoring.
- • Weather-resistant IP-rated design: Rated IP65 to prevent environmental degradation from moisture and debris in exterior wall installations.
- • Compact, professional finish: Features a sleek toughened glass front and aluminum border, ensuring durability while matching modern architectural finishes.
Key Features & Technical Specifications
| Product Type | IP-based access control terminal (controller + reader in one) |
| Credential Types | RFID card + NFC mobile access |
| RF Card Frequencies | 13.56 MHz & 125 kHz |
| Card Capacity | Up to 20,000 cards |
| Event Log Capacity | Up to 50,000 events |
| Network Interface | RJ45 Ethernet, 10/100 Mbps adaptive |
| Power Options | 802.3af PoE or 12V DC (if not using PoE) |
| Relay Output | 1 relay output |
| Inputs | 2 inputs |
| Tamper | Supported |
| Ingress Protection | IP65 |
| Mounting | Flush-mounted or wall-mounted |
| Dimensions | Flush: 86 × 86 × 16 mm; Wall: 86 × 86 × 27 mm |
| Operating Conditions | -20°C to +55°C; 10–90% RH (non-condensing) |
| Materials | Front panel: Toughened glass; Frame: Aluminium |
Ideal Use Cases
Office Entries
Control employee entry via RFID badges or smartphone NFC while maintaining a clean, modern entrance profile.
Commercial Tenancies
Secure common doors across multi-tenant buildings without introducing bulky exterior hardware control boxes.
Warehouses & Staff-Only Areas
Deliver dependable entry control with straightforward user credentials and durable environmental protection.
Gates and External Doors
Deploy the IP65-rated housing confidently on exterior perimeter gates and weather-exposed doors.
Frequently Asked Questions
1. Can the A01 be powered by PoE?
The Akuvox A01 natively supports 802.3af Power-over-Ethernet (PoE), delivering power and network connectivity over a single Cat5e/6 cable. This streamlines wiring, cuts installation overhead, and maintains a clean door setup. Where PoE infrastructure is absent, a 12V DC power source can be connected directly.
2. What credential options does the A01 support?
The terminal supports multi-frequency RFID cards along with NFC mobile credentials. This dual capability lets sites maintain traditional RFID card workflows while enabling smooth adoption of mobile access via smartphone for authorized personnel.
3. Is the A01 suitable for outdoor installation?
Yes, featuring an IP65 protection rating, the unit offers robust defense against dust and water entry. It is well-suited for exposed entry points, external doors, and outdoor pedestrian gates when installed and sealed according to standard practices.
