SKU:IPC-HDW3666EMP-S
Dahua 6MP IPC-HDW3666EMP-S (IR) WizSense Network Camera
Dahua 6MP Lite Series Infrared (IR) Fixed Focal Eyeball WizSense Network Camera, White color (IPC-HDW3666EMP-AS-28) supports intelligent functions with advanced deep learning algorithm, such as perimeter protection and smart motion detection. With starlight technology, this series camera provides a better image effect in the condition of low illuminance.
Features
- 6-MP 1/2.7″ CMOS image sensor, excellent low luminance performance and high definition of images.
- Outputs max. 6 MP (3072 × 2048) @25/30 fps
- H.265 codec, high compression rate, ultra-low bit rate.
- Built-in IR LED, max. IR distance: 30 m.
- ROI, SMART H.264 +/H.265+, AI H.264/H.265, flexible coding, applicable to various bandwidth and storage environments.
- Rotation mode, WDR, 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
- Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human).
- Abnormality detection: Motion detection, privacy masking, scene changing, audio detection, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection.
- Max. 256 G Micro SD card. built-in Mic.
- 12 VDC/PoE power supply, easy for installation.
- IP67 protection.
- SMD 4.0, AI SSA.
-
Vendor:
Dahua
- Tags: 3x66, 6mp, Turret camera, Wizsense
- Specifications
| Category | Parameter | Details |
| Camera | Image Sensor | 1/2.7″ CMOS |
| Max. Resolution | 3072 (H) × 2048 (V) | |
| Scanning System | Progressive | |
| ROM / RAM | 128 MB / 1 GB | |
| Electronic Shutter | Auto/Manual 1/3 s–1/100,000 s | |
| Min. Illumination | 0.005 lux@F1.4 (Color); 0.0005 lux@F1.4 (B/W); 0 lux (IR on) | |
| S/N Ratio | >56 dB | |
| Illumination | 30 m (164.04 ft) distance; 2 IR LEDs | |
| Pan/Tilt/Rotation | Pan: 0°–360°; Tilt: 0°–78°; Rotation: 0°–360° | |
| Lens | Lens Type | Fixed-focal (M12 mount) |
| Focal Length | 2.8 mm; 3.6 mm | |
| Max. Aperture | F1.4 | |
| Field of View |
2.8 mm: H: 97°, V: 71°, D: 129° 3.6 mm: H: 80°, V: 57°, D: 107° |
|
| DORI (2.8mm) | Detect: 63.6m; Observe: 25.4m; Recognize: 12.7m; Identify: 6.4m | |
| DORI (3.6mm) | Detect: 85.4m; Observe: 34.2m; Recognize: 17.1m; Identify: 8.5m | |
| Intelligence | IVS (Perimeter) | Tripwire, intrusion (Human & Vehicle classification) |
| Features | AI SSA, Quick Pick, Smart Search | |
| Video | Compression | H.265; H.264; H.264H; H.264B; MJPEG (Sub stream) |
| Smart/AI Codec | Smart H.265+; Smart H.264+; AI H.265; AI H.264 | |
| Frame Rate | Main stream: 3072 × 2048 @ 1–25/30 fps | |
| WDR / BLC / HLC | 120 dB / Yes / Yes | |
| Image Settings | 3D NR, SSA, RoI (4 areas), Defog, Mirror, Privacy Masking (4 areas) | |
| Image Rotation | 0°/90°/180°/270° | |
| Audio | Microphone | Built-in MIC |
| Compression | G.711a; G.711Mu; PCM; G.726; G.723 | |
| Network | Network Port | RJ-45 (10/100 Base-T) |
| Protocol | IPv4/v6, HTTP, TCP, UDP, ARP, RTP, RTSP, SMTP, FTP, DHCP, DNS, etc. | |
| Interoperability | ONVIF (CGI); P2P; Milestone; Genetec | |
| Cyber Security | Video/Firmware encryption, HTTPS, 802.1x, IP/MAC filtering, syslog | |
| Storage | Micro SD card (max. 256 G); NAS; FTP; SFTP | |
| Power | Power Supply | 12 VDC/PoE (802.3af) |
| Consumption | Basic: 4.3 W; Max (WDR+IR+Intell.): 8.9 W (PoE) | |
| Environment | Operating Temp | –40 °C to +60 °C (–40 °F to 140 °F) |
| Protection | IP67 | |
| Structure | Casing | Metal |
| Dimensions | 93.6 mm × Φ106.0 mm (3.69″ × Φ4.17″) | |
| Weight | Net: 500 g (1.10 lb); Gross: 770 g (1.70 lb) |
