SKU:TKP-1068B
Access Control Electronic Touch Keypad, Waterproof - TKP-1068B
Login to buyThe access host supports 125kHz EM cards. It controls 1 door, supports up to 2000 users in total, each user have one card and one PIN. The access control unit supports 1 master code, one manager add a card, one manager delete card, 1 anti-duress card and 1 anti-duress PIN, providing users with easy operation and a safe guarantee.
Features:
- Functions:
Card reading and keypad operation
Door lock control
Alarm and doorbell activation
Exit button functionality
Magnetic contact switch monitoring (for door status)
- Capacity:
Supports 1 door
Up to 2,000 users (each with 1 card & 1 PIN)
- Security Features:
1 master code
Manages card adding/deleting
1 anti-duress card and PIN for emergency situations
- Benefits:
Easy operation
Secure access control
-
Vendor:
TotalSE
- Tags: Clearance
- Description
Product Overview
The TKP-1068B is a standalone electronic access control keypad for a single door, reading 125kHz EM proximity cards and PIN codes for up to 2,000 users — no separate control panel or software required. It builds on our TKP-1068A keypad with a wider set of door-monitoring inputs: a dedicated exit button connection, magnetic contact (door sensor) monitoring, and alarm/doorbell activation.
Those extra inputs mean the TKP-1068B can do more than just release the lock — it can also confirm whether the door is actually closed, provide a proper request-to-exit connection, and trigger an alarm or doorbell output, all from one unit. A master code, card add/delete management and anti-duress card and PIN round out the security features. Supplied directly through Total Security Equipment.
Key Capabilities
Magnetic Contact Monitoring
Connects to a door sensor so the system knows whether the door is actually open or closed, not just when it's unlocked.
Dedicated Exit Button Input
A proper request-to-exit connection for a push-button release from inside.
Alarm & Doorbell Activation
Built-in outputs for triggering an alarm condition or a doorbell function from the same unit.
2,000-User Capacity
Each of up to 2,000 users gets their own card-and-PIN combination, managed with a master code.
Best For
Sites that want to know if a door has been left open, not just whether it's unlocked.
Installs that want a dedicated exit button rather than relying on the keypad alone.
A door that needs both access control and a basic alarm or doorbell function in one unit.
Why Choose This Keypad
The TKP-1068B is the more complete door-control option in our 1068 series — where the standard TKP-1068A focuses purely on card + PIN entry, the 1068B adds the monitoring and alarm inputs a proper install often needs: a door sensor connection, a dedicated exit button, and alarm/doorbell activation. That means fewer separate components to wire in for a single-door job that needs more than just "unlock on valid card." Available from Total Security Equipment.
Buyer Decision Tips
Key Features & Technical Specifications
| Model SKU | TKP-1068B |
| Product Type | Standalone electronic access control touch keypad with door sensor, exit button & alarm/doorbell inputs |
| Card Frequency | 125kHz EM proximity card |
| Doors Controlled | 1 |
| User Capacity | Up to 2,000 users, each with one card + one PIN |
| Door Monitoring | Magnetic contact (door sensor) input |
| Exit Button | Dedicated request-to-exit input |
| Alarm/Doorbell | Built-in alarm and doorbell activation |
| Security Functions | Master code, card add/delete management, anti-duress card and PIN |
| Housing | Aluminium alloy, waterproof (exact IP rating not confirmed for this model — our sibling TKP-1068A is IP65) |
| Dimensions & Weight | Not confirmed for this specific model — our sibling TKP-1068A measures ≈158.6×43×21.7mm / ≈500g; confirm with our team |
| Power Supply | Not confirmed for this specific model — our sibling TKP-1068A runs on DC 12-24V; confirm exact rating with our team |
| Operating Temperature | Not confirmed for this specific model — confirm with our team |
| Mounting | Wall or gate-post mount, indoor or outdoor |
| Warranty | Confirm current warranty term with our team |
Ideal Use Cases
Fire/Life-Safety-Conscious Doors
Dedicated exit button input supports a proper request-to-exit setup.
Doors Left-Open Monitoring
Magnetic contact input lets the system flag a door that hasn't closed properly.
Warehouses & Staff Entries
Card + PIN access for a single staff door with proper monitoring built in.
Front Entries Wanting a Doorbell
Built-in doorbell activation alongside access control on the same unit.
Choosing the Right Keypad
Choose the TKP-1068B if:
You want door sensor monitoring, a dedicated exit button input, or alarm/doorbell activation alongside card + PIN access.
Choose the TKP-1068A instead if:
You just need straightforward card + PIN entry without the extra monitoring inputs. Ask our team to compare the two side by side.
FAQs
1. How is this different from the TKP-1068A?
The TKP-1068B adds a magnetic contact (door sensor) input, a dedicated exit button connection, and alarm/doorbell activation — features the standard TKP-1068A doesn't have.
2. Does it include the door sensor and exit button?
No — this unit provides the wiring inputs for them. The magnetic contact sensor and exit button hardware are sold separately. Speak with our team about a complete parts list.
3. How many users can it store?
Up to 2,000 users, each assigned their own card and PIN combination.
4. Is it waterproof for outdoor use?
It's built in an aluminium alloy waterproof housing. Please confirm the exact IP rating with our team if you need a specific certified rating for your site — our sibling TKP-1068A is rated IP65.
5. Where can I buy this keypad in Australia?
It's available directly from Total Security Equipment.
Additional Information
Melbourne HQ
26 Davies Ave., Sunshine North, VIC 3020
03 9079 5566
Sydney Branch
38 Lisbon St., Fairfield East, NSW 2165
02 8722 0348
Ordering & Support
- Australia-wide shipping
- Trade accounts and volume pricing
- Phone support on door hardware & wiring
- Download Spec Sheet
Not sure if this keypad or the simpler TKP-1068A suits your site, or what door sensor and exit button hardware you'll need? Call our Melbourne team on 03 9079 5566 or Sydney on 02 8722 0348 — describe your setup and we will tell you honestly what fits.
