SKU:TL-SF1005P
TP-Link 5-Port 10/100Mbps Desktop Switch with 4-Port PoE+ - TL-SF1005P
Login to buyFeatures:
- 5× 10/100 Mbps RJ45 ports
- 4× PoE+ ports transfer data and power on individual cables
- Works with IEEE 802.3af/at compliant PDs
- Supports PoE Power up to 30 W for each PoE port
- Supports PoE Power up to 67 W for all PoE ports*
- Up to 250m data and power transmitting range under Extend Mode
- Priority Mode ensures high priority of ports 1–2 to guarantee the quality of the sensitive application
- PoE Auto Recovery guarantees the stable operation of PoE devices by automatically rebooting the dropped or unresponsive PD devices
- Plug and play with no configuration required
-
Vendor:
TP-Link
- Tags: Poe
- Description
Product Overview
The TP-Link TL-SF1005P is a compact 5-port desktop switch built to power and connect small PoE deployments — think a handful of IP cameras, access points, or intercoms — without needing a separate power injector for every device. Four of its five ports supply PoE+ power directly over the same cable that carries data, while the fifth is a standard data-only uplink back to your router or main switch.
With up to 67W of PoE budget shared across the four PoE+ ports, Extend Mode for longer cable runs, and Priority Mode to protect your most important connection, it is a practical, no-configuration option for small camera or access-control jobs. Supplied through Total Security Equipment.
Key Capabilities
4 PoE+ Ports, Up to 67W Total
Ports 1–4 supply IEEE 802.3af/at PoE+ power, up to 30W per port and ≈67W shared across all four.
Extend Mode to 250m
Extend Mode stretches data and power transmission up to 250m on supported PoE ports, useful for longer camera runs.
Priority Mode & PoE Auto Recovery
Priority Mode protects ports 1–2 for your most sensitive devices; PoE Auto Recovery reboots unresponsive PDs automatically.
Plug & Play, No Config
Fully unmanaged — connect your PoE devices and it works, with no software or login required.
Best For
Small Camera Deployments
Powers up to 4 IP cameras directly, without separate PoE injectors.
Access Control & Intercoms
A tidy way to power a door station, keypad, or access point over a single cable run.
Small Add-On PoE Points
Extends PoE to a single room or equipment cupboard without a large rack switch.
Why Choose This Switch
Not every PoE job needs a large rack-mount switch. The TL-SF1005P packs 4 PoE+ ports and a genuinely useful power budget into a small desktop unit — ideal when you only need to power a few cameras or access devices in one location. It is backed by TP-Link's long track record in unmanaged switching and is available from Total Security Equipment.
Buyer Decision Tips
Key Features & Technical Specifications
| Model SKU | TL-SF1005P |
| Brand | TP-Link |
| Ports | 5 × 10/100Mbps RJ45 ports (ports 1–4 PoE+, port 5 data-only) |
| PoE Standard | IEEE 802.3af/at compliant (current-production units); some older hardware versions are 802.3af only — confirm with our team if unsure |
| PoE Power Budget | Up to 30W per PoE port; ≈67W total across all PoE ports (current-production units; older versions ≈58W — confirm with our team) |
| Extend Mode Range | Up to 250m for data and power under Extend Mode |
| Switching Capacity | ≈1.2Gbps |
| MAC Address Table | 2K entries |
| Management | Unmanaged — plug and play, no configuration or software required |
| Power Supply | External power adapter included (rating varies by hardware version — confirm with our team if you need a replacement adapter) |
| Design | Fanless, metal case, desktop or wall-mount |
| Operating Temperature | 0°C to 40°C |
| Dimensions | ≈99.8mm × 98mm × 25mm |
| Weight | ≈0.775kg (reseller-reported; confirm with our team if exact weight matters for your install) |
| Warranty | Commonly listed as 3 years by Australian resellers — confirm current warranty term with our team |
Ideal Use Cases
Small CCTV Installs
Powers up to 4 IP cameras from one compact desktop unit.
Door Access & Intercoms
A single-cable power-and-data solution for keypads, readers, and door stations.
Wall-Mounted Installs
Compact enough to mount out of the way in a small equipment space.
Extending PoE to a New Area
Adds a local PoE point without running a new home-run cable for every device.
FAQs
1. How many ports supply PoE power?
4 of the 5 ports (ports 1–4) supply PoE+ power; port 5 is a standard data-only uplink port.
2. What is the total PoE power budget?
Current-production units are rated for up to 67W total across the 4 PoE+ ports (30W max per port). Some older hardware versions were rated lower, at 58W total. Confirm your unit's exact rating with our team if your total device draw is close to the limit.
3. Is this Gigabit Ethernet?
No — this switch runs at 10/100Mbps (Fast Ethernet), not Gigabit. This is normal for PoE cameras and access devices, but ask our team if your devices need Gigabit speeds.
4. Do I need to configure it before use?
No — it's fully unmanaged and plug-and-play. Just connect your PoE devices and it works, with no software or login required.
5. Where can I buy this switch in Australia?
It's available directly from Total Security Equipment.
