SKU:RG-ES226GC-P
Ruijie RG-ES226GC-P PoE+ Switch
Login to buyFeatures
- 26-Port gigabit cloud managed switch with 24 PoE+ ports
- Cost-Effective Smart Cloud Managed Switches
- IP Camera Recognition, Unique Value for CCTV Network
- Automatic Loop Prevention Ensures Service Continuity
- Lifetime management on Ruijie Cloud at anytime anywhere
-
Vendor:
Ruijie
- Tags: Poe
- Description
Product Overview
The Ruijie RG-ES226GC-P is a 26-port Gigabit smart cloud-managed switch with 24 PoE+ ports plus 2 SFP fibre slots — the largest and highest-capacity switch in our Ruijie range. Housed in a 1U rack-mountable metal case (with mounting brackets included), it's built for larger CCTV deployments and comms rooms, with built-in IP camera recognition and automatic loop prevention (RLDP) to keep the network running if a cable is accidentally looped back on itself.
Being cloud-managed means you can monitor and configure the switch remotely via the Ruijie Cloud platform — useful for installers managing multiple sites, or for checking on a system without a truck roll. The 2 SFP slots let you run a fibre uplink back to your core network over longer distances than copper allows. Supplied directly through Total Security Equipment.
Key Capabilities
26 Ports, 24 PoE+, 2 SFP
24 PoE+ (802.3at/af) RJ45 ports for cameras, plus 2 dedicated SFP fibre slots for a long-distance uplink.
370W PoE Budget
The largest shared power budget in our Ruijie range, sized for a full 24-camera deployment.
1U Rack-Mount Metal Case
Ships with mounting brackets included, ready to install straight into a standard equipment rack.
Ruijie Cloud Management
Free lifetime remote management and monitoring via the Ruijie Cloud platform, from anywhere.
Best For
Powers and networks up to 24 IP cameras from one rack-mounted switch.
SFP slots support a fibre uplink for longer-distance or building-to-building connections.
1U rack-mount form factor with brackets included fits straight into a standard rack.
Why Choose This Switch
A dedicated CCTV-oriented switch does more than a generic unmanaged one — the RG-ES226GC-P recognises connected IP cameras, protects the network from accidental loop-backs, and can be checked on remotely through Ruijie Cloud without a site visit. With 24 PoE+ ports, a 370W shared budget and 2 SFP fibre slots, it's the top of our Ruijie range — built for a full-scale camera deployment in a proper comms rack rather than a shelf-top desktop unit. Available from Total Security Equipment.
Buyer Decision Tips
Key Features & Technical Specifications
| Model SKU | RG-ES226GC-P |
| Brand | Ruijie (Reyee) |
| Ports | 26 total: 24 × 10/100/1000BASE-T PoE+ RJ45 ports plus 2 × 1G SFP fibre slots |
| PoE Standard | IEEE 802.3at (PoE+) / 802.3af, 370W total PoE budget shared across the 24 PoE ports |
| Switching Capacity | 52Gbps |
| Forwarding Rate | 38.7 Mpps |
| Form Factor | 1U rack-mountable metal case (mounting brackets included) |
| Power Supply | Internal, 100–240VAC input, ≈443W max consumption |
| Management | Ruijie Cloud (remote), free lifetime management; WebUI and app management also supported |
| Key Features | IP camera/NVR recognition, automatic loop prevention (RLDP), port isolation, PoE watchdog, individual port reboot, mobile VLAN configuration |
| In the Box | Switch, rack mounting brackets, foot pads, screws, power cable, quick start guide |
| Operating Temperature | 0°C to 40°C |
| Dimensions | ≈440mm × 295mm × 45mm (1U rack height) |
| Weight | ≈4.0kg |
| Warranty | Commonly listed as 3 years by Ruijie — confirm current warranty term with our team |
Ideal Use Cases
Large IP Camera Systems
Powers and networks up to 24 PoE IP cameras from a single rack-mounted switch.
Multi-Building Sites
SFP fibre uplink extends reliable connectivity over longer distances than copper.
Comms Rooms & Server Racks
1U rack-mount metal case with brackets included fits straight into standard rack gear.
Multi-Site Installers
Ruijie Cloud lets you check on and manage several large installs remotely.
Choosing the Right Ruijie Switch
RG-ES226GC-P (this product)
26 ports, 24 PoE+ & 2 SFP, 370W budget, rack-mount. Choose this for up to 24 cameras.
RG-ES218GC-P
18 ports, 16 PoE+ & 2 SFP, 240W budget, rack-mount. Choose this for up to 16 cameras.
RG-ES209GC-P
9 ports, 8 PoE+, 120W budget, compact desktop. Choose this for a mid-size job.
RG-ES205GC-P
5 ports, 4 PoE+, 54W budget, compact desktop. Choose this for a smaller job, at the lowest price point.
FAQs
1. How many cameras can this power?
Up to 24 PoE+ cameras, using the 24 dedicated PoE ports. The total PoE budget is 370W shared across those ports, so check your cameras' combined power draw.
2. Is rack-mounting hardware included?
Yes — it ships with mounting brackets, foot pads and screws, so it's ready to install into a standard rack out of the box.
3. Do the SFP ports come with fibre modules included?
No — the 2 SFP slots accept separately-purchased SFP transceiver modules and fibre cabling. Ask our team about compatible modules for your setup.
4. Do I need a Ruijie Cloud account to use it?
No — the switch works locally without one. A free Ruijie Cloud account is only needed if you want to monitor or configure it remotely over the internet.
5. Where can I buy this switch in Australia?
It's available directly from Total Security Equipment.
Additional Information
Melbourne HQ
26 Davies Ave., Sunshine North, VIC 3020
03 9079 5566
Sydney Branch
38 Lisbon St., Fairfield East, NSW 2165
02 8722 0348
Ordering & Support
- Australia-wide shipping
- Trade accounts and volume pricing
- Phone support on PoE budget & network design
- Download Spec Sheet
Not sure if this switch's PoE budget covers your cameras, or which size in the range suits your job? Call our Melbourne team on 03 9079 5566 or Sydney on 02 8722 0348 — describe your setup and we will tell you honestly what fits.
